Sizing a generator is straightforward: match the output to the room volume and the surface finish. Keeping it alive in Nepal is the harder problem, and it comes down to water.
Every generator we supply is quoted with its treatment, its drain and its service interval, because a generator without those three is a replacement waiting to happen.
Installation requirements
- Supply
- 3-phase 400V for 9 kW and above
- Water
- Softened, below 150 ppm hardness
- Drain
- 22 mm gravity to a tundish — never direct
- Location
- Within 12 m of the room, ventilated, under 40 °C
- Access
- 300 mm above, 150 mm each side
What actually decides it
- 01
Auto-drain is the feature that matters
Draining and flushing the tank after every session is what turns descaling from a rebuild into an hour of work.
- 02
Plant rooms get hot
A generator in an unventilated cupboard will trip on high ambient. Plan the ventilation with the location.
- 03
Steam head placement
At least 200 mm above floor level and away from the seat. It is a comfort and a safety detail, and it is fixed in the drawing, not on site.
Where to go next
Further reading
Questions
- Do we need a water softener?
- In the Kathmandu valley, almost always. Untreated supply here scales a generator within a season.
- What size generator for a 10 m³ steam room?
- A 9 kW unit covers 8–12 m³ with a tiled finish. Natural stone absorbs more and pushes you up a size.
- Can you service a generator we already have?
- Yes, after an inspection. If it is not worth maintaining we will say so and quote the replacement instead.
Tell us the room.
Dimensions, the supply you have, and what you want to happen in it. We will come back with a system list and an indicative budget.
